Hewlett Packard Enterprise 2530 8-port Switch Pwr Adptr **New Retail**, J9820A

Productspecificaties

Artikelnummer(s)

EAN

0888182309025

Beheerfuncties

Switch type

Managed

Data-uitwisseling

Switchingcapaciteit

960 Gbit/s

Throughput

571,4 Mpps

Latentie (1 Gbps)

2,9 µs

Latentie (10 Gbps)

2 µs

Design

Stapelbaar

Ja

Kleur van het product

Grijs

Prestatie

Type processor

Ja

Frequentie van processor

1200 MHz

Type geheugen

DDR3-SDRAM

Intern geheugen

4096 MB

Flash memory

16 MB

Energie

Vermogenstoevoer inclusief

Nee

AC-ingangsspanning

200 - 240 V

Netvoeding voetnoot

2 power supply slots 1 minimum power supply required (ordered separately)

Power over Ethernet (PoE)

Power over Ethernet (PoE)

Nee

Overige specificaties

Latentie

1000 Mb Latency: < 2.8 µs; 10 Gbps Latency: < 1.8 µs; 40 Gbps Latency: < 1.5 µs

Geheugen en processor

Depend on the model: Dual Arm Cortex A9 at 1 GHz; Packet buffer size: 13.5 MB internal Arm 11 at 450 MHz; Packet buffer size: 18 MB internal. Dual Arm Cortex A9 at 1; Packet buffer size: 13.5 MB internal Arm 11 at 550 MHz; Packet buffer size: 18 MB internal. Dual Arm Cortex A9 at 1 GHz; Packet buffer size: 13.5 MB internal Freescale P2020 dual core at 1.2 GHz, 16 MB flash, 1 GB SD Card, 4 GB DDR3 SODIMM.

Aansluitingen

6 open module slots Supports a maximum of 144 autosensing 10/100/1000 ports or 144 SFP ports or 48 SFP+ ports or 48 HPE Smart Rate Multi-Gigabit or 12 40 GbE ports, or a combination.

Prestatiebeheer

HPE Aruba Networking Management Software HPE Aruba Networking Central HPE Intelligent Management Center Basic Software Platform (IMC) Command-line interface Web browser Configuration menu Out-of-band management (RJ-45 Ethernet) Out-of-band management (serial RS-232C or micro USB) SNMP manager

Gewicht (imperiaal)

11,1 kg (24.5 lbs)

Afmetingen (B x D x H) (Brits)

444,5 x 450,9 x 175,3 mm (17.5 x 17.8 x 6.9")

Eisen aan de omgeving

Warmtedissipatie

2450 BTU/h

Gewicht en omvang

Breedte

444,5 mm

Diepte

450,9 mm

Hoogte

175,3 mm

Gewicht

11,1 kg
